Grass Chopper Machine

This grass chopper were suitable for cutting corn stalk ,grass,cotton stalk ,wheat stalk ,straw ,soybean stalk etc, dry or wet grass ,which is an ideal equipment for large ,medium-sized and small siz...

Counseling hotline: 0086 - 0372 2072505

Recommend similar products for you

Batch?
Features

This series chaff cutter were suitable for cutting corn stalk ,grass,cotton stalk ,wheat stalk ,straw ,soybean stalk etc, dry or wet grass ,which is an ideal equipment for  large ,medium-sized and small size farm for feeding cow,horse,pig ,rabbit,deer,sheep etc.



Working Principle :

When machine working ,the processed forage grass under the direct effect of straight  roller,feed into the chopped grass cutter roller turn motivation mechanism, make use  of cutting roller centrifugal wind caused by high speed rotating operation ,to send the crushed grass out machine 1 to 5 meters away.


Parameter

Grass Chopper Machine Technical Parameter

Model

GS-0.6

GS-0.8

Power

2.2-4.8 kw

2.2-4.8 kw

Voltage

220v/380v

220v/380v

Shaft Speed

1080r/min

1080r/min

Knives

4 Pcs

6 Pcs

Capacity(kg/h)

400-900kg

400-900kg

Cutting size

9-30mm

9-30 mm

Dimension

105*51*80cm

105*58*80cm

N.W ( kg)

55kg

65kg

Suitable for

Duck,goose,rabbit,sheep,cow,pig etc.poultry



Process material

Moisture Content %

Capacity (t/h)

Wet corn stalk

65 %

1.4 t/h

Dry corn stalk

17 %

0.5 t/h

Green grass

65 %

1 t/h

Dry straw

17%

0.4 t/h

Dry wheat stalk

17 %

0.3 t/h
